| Specification | Details |
|---|---|
| LED Panel Specs | |
| Pixel Pitch | 5.71 mm |
| Pixel Configuration | 1R1G1B |
| LED Type | SMD 2727 |
| Brightness (max) | 6000 nit |
| Color Temperature | 3500 K–10000 K (adjustable) |
| Viewing Angle | H160° / V90° |
| Pixel Density | 30,625 dots/m² |
| Dimensions |
Module: 48 × 32 cm Cabinet: 96.0 × 96.0 × 8.5 cm |
| Resolution |
Module: 84 × 56 dots Cabinet: 168 × 168 dots |
| Weight | 28 kg (cabinet) |
| Material | Aluminium (cabinet) |
| Operating Temp | –40 ℃ to +60 ℃ |
| Operating Humidity | 10 %–80 % RH |
| Storage Temp | –40 ℃ to +60 ℃ |
| Storage Humidity | 10 %–80 % RH |
| IP Rating | Front IP68 / Rear IP66 |
| Aspect Ratio | 1:1 |
| Gray Scale | 14 bit |
| Contrast Ratio | 6000:1 |
| Refresh Rate | 3840 Hz |
| Input Voltage | AC 110–220 V (±10 %) |
| Power Consumption |
Standard: 150 W/m² Maximum: 550 W/m² |
| Installation | Wall Mounted / Floor Mounted |
| Maintenance | Front / Rear Maintenance |
| Lifespan | ≥ 100,000 H |
| Signal Transmission Distance |
CAT5 cable (L ≤ 100 m) Multi‑mode fiber (L ≤ 300 m) Single‑mode fiber (L ≤ 10 km) |
DISPLAY
Aspect Ratio
1:1
Resolution
30,625 dot/m2
Backlight
Brightness / Luminance
≥ 6000 cd/m²
Contrast
5000:1
Display Colour
14 bit
Viewing Angle (H/V)
H170°/V90°
Refresh Rate
3840Hz
SIGNALS
Input
CAT5 Cable ( L≤100m ),single mode fiber ( L≤10km )
Audio
Output
GENERAL
Power Supply
220V AC, 220V AC
Consumption Standard
)
Netweight
28kg per cabinet
Gross Weight
Wall Mount
Dimension without stand (W×H×D)
)
Package(W×H×D)
)
ENVIRONMENT
Operating Temperature
-40℃~+60℃
Operating Humidity
10~95%RH
